| Item | Indoor P 3.91 | Indoor P 4.81 | Indoor P 2.976 | |
| Module | Panel Dimension | 250mm(W)*250mm(H) | 250mm(W)*250mm(H) | 250mm(W)*250mm(H) |
| Pixel pitch | 3.91mm | 4.81mm | 2.976mm | |
| Pixel Density | 65536dotm 2 | 43264dot/m² | 112896dot/m 2 | |
| Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B | |
| LED specification | SMD 2121 | SMD 2121 | SMD 2121 | |
| Pixel resolution | 64dot*64dot | 52dot*52dot | 84dot*84dot | |
| Average power | 35W | 35W | 35W | |
| Panel weight | 0.55KG | 0.47KG | 0.5KG | |
| Cabinet | Cabinet size | 500*1000mm*85mm，500*500*85mm | 500*1000mm*85mm，500*500*85mm | 500*500*85mm，500*1000*85mm |
| Cabinet Resolution | 128dot*256dot， 128*128dot |
104dot*208dot 104dot*104dot |
168*168dot 168*336mm |
|
| Quan tty of panel | 8pcs， 4pcs | 8pcs， 4pcs | 4pcs | |
| Hub connecting | HUB 75-E | HUB 75-E | 26P | |
| Best viewing angle | 170/120 | 170/120 | 140/120 | |
| Best viewing distance | 3-30M | 4-40M | 3-30M | |
| Operating temperature | -10C°~45C° | -10C°~45C° | -10C°~45C° | |
| Screen powersupply | AC110V/220V-5V40A | AC110V/220V-5V40A | AC110V/220V-5V40A | |
| Maxpower | 800W/m² | 800W/m² | 800W/m² | |
| Average power | 400W/m² | 400W/m² | 400W/m² | |
| TechnicalSign all ndex | Driving IC | ICN 2065/16380 | ICN 2065/16380 | ICN 2065/ 16380 |
| Scan Rate | 1/16S | 1/13S | 1/28S | |
| Refresh f repu ency | 1920-3840HZ/S | 1920-3840HZ/S | 1920-3840HZ/S | |
| Display color | 1R1G1B | 1R1G1B | 1R1G1B | |
| Brightness | 800-1000cd/m² | 800-1000cd/m² | 800-1000cd/m² | |
| Lifespan | 100000 Hours | 100000 Hours | 100000 Hours | |
| Conrol di tance | <100M | <100M | <100M | |
| Operating Humidity | 10-90% | 10-90% | 10-90% | |
| IP protective index | IP43 | IP43 | IP43 |
